Flexible Graphite Paper/graphite Foil/graphite Sheet In Roll Gasket Material Product Description

date：2017-04-27

read：

Flexible Graphite Paper/graphite Foil/graphite Sheet In Roll Gasket Material

Graphite sheet is made from flake graphite with high carbon content which is gone through chemical treatment ,expanding Flexible graphite sheet (roll)

Advantages of graphite paper:

. High thermal conductivity

. Low thermal resistance

. RoHS & UL compliance

Application of graphite paper:

. Intelligent mobile phone

. Laptop/notebook

. Telecom device

. Handheld device

. Digital camera

. Tablet PC

. Others

TECHNICAL SHEET:(COMMON MODELS)

TECHNICAL SHEET:(COMMON MODELS)

Test Content	TCGS-S Value	TCGS-S Value	TCGS-S+PET Value	Unit	Test Method
Model Number	ZZX-250	ZZX-350	ZZX-450	-----	----
Color	Black	Black	Black	------	Visual
Material	Graphite	Graphite	Graphite	------	Visual
Thickness	0.05-0.5	0.05-0.5	0.05-0.5	mm	ASTM D374
Specific Gravity	1.5	0.9-2.0	1.5-1.8	g/cc	ASTM D792
Continuou Use Temp	-40~+500	-40~+500	-40~+500	°C	EN344
Tensile Strength	715PS	715PS	715PS	4900Kpa	ASTM F-152
Volume Resistivity	3.0*1013	3.0*1013	3.0*1013	Ω/cm	ASTM D257
Hardness	80	80	>80	Shore C	ASTM D2240
Flame Rating	V-0	V-0	V-0	----	UL-94
Thermal Conductivity (vertical direction)	5	4	3	W/m-k	ASTM D5470
Thermal Conductivity (horizontal direction)	300-500	300-500	300-500	W/m-k	ASTM D5470


Size: As per your requirement, accept customized.

We also can supply other types of graphtie block, like moulded graphite block, brick, and all of the machined graphite parts.

Packaging & Shipping


Our Services

1. Quality assurance,we use high grade raw material and do strict inspect during the whole procession. All products adopt GB,ISO,ASTM,BS,JIS and DIN standard as per requirement. ISO, BV, TUV, SGS certified.
2. Provide professional designing solution, field technical assitance and any other consulting.
3. Price advantage, provided by manufacturer directly,save much intermediate fees.
4. Professional team, specialized in refractory production since 2000,with advanced technology and vast experience.
5. High production capacity, fast delivery of goods.
6. 24*7 online service.
7. OEM service available.
